<heading-style-h2>POTEAU TERRE<heading-style-h2>

<heading-style-h6>Allows anchors to be fixed in natural and/or sandy ground.<heading-style-h6>

<heading-style-h3>Installation procedure<heading-style-h3>

1. - Drill the ground with an auger bit of at least 80 cm x 35 mm.
- Check that there are no stones or obstacles.
- If an obstacle is found, move the post location slightly.
2. - Place the posts with the upper gussets perpendicular to the direction of the load.
- On sloping ground, orient the gussets perpendicular to the slope.
3. - Drive the posts in with a sledgehammer and a dedicated driving cap so as not to damage the fixing head.
- The posts must be driven in up to half of the “HOOKT” logo engraved on the side.
4. - Once the posts are installed, mount the New Pro interfaces and fit the lifeline cables.
- Make sure the tension is correct and the anchor points are aligned.
5. - Check that the posts hold firmly and show no abnormal deformation.
- Make sure the system is installed with redundancy (at least two posts).
- To date, the posts are not certified as individual anchor points, only for mounting the New Pro lifeline.

If the lifeline consists of two posts, perform a 5 kN pull test on each anchor.
If the lifeline consists of three or more posts, perform a 5 kN pull test on the whole line.

Warning: ground posts are designed to deform from 6 kN. If deformed, the post can no longer be used and must be replaced.

USE

PRO

Matrix
Material
316L stainless steel
Bec
System
Bolts
Tightening torque
Upper stop
Lower stop
3-piece games
Diameter
mm
Vis
Angle
°
specifications
security
Norm
EU certificate type no.
Certification body - Conformity certificate number
Long axis break
Kn
Minor axis break
Kn
Coque
Resistance
Usage load resistance (CMU)
20
Kn
Resistance to breaking load (CMR) or sliding
Kn
Sliding
Kn
Number of users
5 users max.
Breaking resistance
lb
Masse
lb
Pose
Height
1000
mm
Fixation
Montage
Section
